| Modes of Ventilation |
 |
Volume Controlled (VCV), Assist/Control |
|
Pressure Controlled (PCV) , Assist/Control |
|
Synchronized intermittent Mandatory Ventitation. |
|
SIMV(VCV) +PSV,SIMV(PCV) +PSV,SIMV(PRVC)+PSV |
|
Spontaneous Ventitltion (SPONT/CPAP)+PSV |
|
Bi Level Ventilation (BIVENT/APRV)+PSV |
|
Non-invasive Ventilation (NIV/CPAP+PSV,NIV/PCV) |
| |
|
Parameters and Ranges
|
|
Tidal volume :20-2500ml |
|
Respiratory rate :1-120bpm |
|
Inspiration time:0.2-9s |
|
Inspiratory pause time:0~4s |
|
Tslop:0~2s |
|
FiO2:21%~100% |
|
PEEP :0-50cm H2O |
|
CPAP(NIV):2-20cm H2O |
|
Psupport :0-90cm H2O |
|
Pinsp :5-90cm H2O |
|
Plow:0-50cm H2O |
|
Esens :5% ~80% |
|
Flow patterns:Square, decelerating |
|
Inspiratory hold |
|
Expiratory hold |
|
Nebulizer :30 or 45 minutes |
|
Auto Tube compensation (ATC) |
|
Compliance compensation |
| |
|
| Monitoring |
|
Pressure values:Pmin,Pplat,Pmean, Ppeak, PEEP |
|
Volume/Flow values:VTI,VTE, MV,MVspont, Leak% |
|
Loops:FLow-Pressure, Pressure-Volume, Flow-Volume |
|
FiO2 |
|
Optional EtCo2 |
